Welcome to kloppy

kloppy is a Python package providing;

  • (de)serializers for soccer tracking- and event data
  • standardized data models
  • filters
  • transformers

All designed to make working with different tracking- and event data a breeze.

It aims to be the fundamental building blocks for loading, filtering and tranforming tracking- and event data.

Project layout

domain/
    models/
    services/
        enrichers/
        matchers/
            pattern/
                regexp/
        tranformers/

infra/
    datsets/
        core/
        event/
        tracking/
    serializers/
        event/
        tracking/

tests/
    files/

Installation

The source code is currently hosted on GitHub at: https://github.com/PySport/kloppy

Installers for the latest released version are available at the Python package index.

# or PyPI
pip install kloppy

(Very) Quickstart

More and more companies are publishing (demo) datasets to get you started. Inspired by the tensorflow_datasets package, we added a "dataset loader" which does all the heavy lifting for you: find urls, download files, organize and load them.

from kloppy import datasets

dataset = datasets.load("metrica_tracking", options={'sample_rate': 1./12, 'limit': 10})

Quickstart

We added some helper functions to get started really quickly. The helpers allow easy loading, transforming and converting to pandas of tracking data.

from kloppy import (
    load_metrica_tracking_data,
    load_metrica_json_event_data,
    load_tracab_tracking_data,
    load_epts_tracking_data,
    load_statsbomb_event_data,
    load_opta_event_data,
    load_sportec_event_data,
    load_wyscout_event_data,
    to_pandas,
    transform
)

# metrica data
dataset = load_metrica_tracking_data('home_file.csv', 'away_file.csv')
# or tracab
dataset = load_tracab_tracking_data('meta.xml', 'raw_data.txt')
# or epts
dataset = load_epts_tracking_data('meta.xml', 'raw_data.txt')

# or event data: statsbomb
dataset = load_statsbomb_event_data('event_data.json', 'lineup.json')
# opta
dataset = load_opta_event_data('f24_data.xml', 'f7_data.xml')
# metrica json
dataset = load_metrica_json_event_data('raw_data.json', 'meta.xml')
# sportec xml
dataset = load_sportec_event_data('events.xml', 'match_data.xml')
# wyscout
dataset = load_wyscout_event_data("events.json")

dataset = transform(dataset, to_pitch_dimensions=[[0, 108], [-34, 34]])
pandas_data_frame = to_pandas(dataset)

Standardized models

Most providers use different names for the same thing. This module tries to model the real world as much as possible. Understandable models are important and in some cases this means performance is subordinate to models that are easy to reason about. Please browse to source of domain.models to find the available models.

Standardized coordinate systems

Every provider has a different coordinate system, which makes it difficult to write code and solutions that can work across data from different providers. When loaded into kloppy, unless specified otherwise when loading it, all data (tracking and event) will be transformed onto kloppy's coordinate system. Kloppy's coordinate system has the origin on the top-left of the field and the axis go from [0, 1]. If you want to know more details about the coordinate systems of each supported provider check out the source of domain.models.

For example StatsBomb has a coordinate system that as the origin on the bottom left, and a fixed dimensions pitch of [120, 80]. If you want to load the data in that coordinate system you need to do:

from kloppy import StatsBombSerializer, Provider

with open(
        f"{base_dir}/files/statsbomb_lineup.json", "rb"
    ) as lineup_data, open(
        f"{base_dir}/files/statsbomb_event.json", "rb"
    ) as event_data:
        dataset = serializer.deserialize(
            inputs={"lineup_data": lineup_data, "event_data": event_data},
            options={"coordinate_system": Provider.STATSBOMB},
        )
        return dataset

        # start working with dataset

However if you want to take advantage of kloppy's standardized coordinate system transformation you can just do:

from kloppy import StatsBombSerializer

with open(
        f"{base_dir}/files/statsbomb_lineup.json", "rb"
    ) as lineup_data, open(
        f"{base_dir}/files/statsbomb_event.json", "rb"
    ) as event_data:
        dataset = serializer.deserialize(
            inputs={"lineup_data": lineup_data, "event_data": event_data},
        )
        return dataset

        # start working with dataset

(De)serializing data

When working with tracking- or event data we need to deserialize it from the format the provider uses. kloppy will provide both deserializing and serializing. This will make it possible to read format one, transform and filter and store in a different format.

from kloppy import TRACABSerializer

serializer = TRACABSerializer()

with open("tracab_data.dat", "rb") as raw, \
        open("tracab_metadata.xml", "rb") as meta:

    dataset = serializer.deserialize(
        inputs={
            'raw_data': raw,
            'meta_data': meta
        },
        options={
            "sample_rate": 1 / 12
        }
    )

    # start working with dataset

or Metrica data

from kloppy import MetricaTrackingSerializer

serializer = MetricaTrackingSerializer()

with open("Sample_Game_1_RawTrackingData_Away_Team.csv", "rb") as raw_away, \
        open("Sample_Game_1_RawTrackingData_Home_Team.csv", "rb") as raw_home:

    dataset = serializer.deserialize(
        inputs={
            'raw_data_home': raw_home,
            'raw_data_away': raw_away
        },
        options={
            "sample_rate": 1 / 12
        }
    )

    # start working with dataset

or EPTS data

from kloppy import EPTSSerializer

serializer = EPTSSerializer()

with open("raw_data.txt", "rb") as raw, \
        open("metadata.xml", "rb") as meta:

    dataset = serializer.deserialize(
        inputs={
            'raw_data': raw,
            'meta_data': meta
        },
        options={
            "sample_rate": 1 / 12
        }
    )

    # start working with dataset

or StatsBomb event data

from kloppy import StatsBombSerializer

serializer = StatsBombSerializer()

with open("events/123123.json", "rb") as event_data, \
        open("lineup/123123.json", "rb") as lineup_data:

    dataset = serializer.deserialize(
        inputs={
            'event_data': event_data,
            'lineup_data': lineup_data
        },
        options={
            "event_types": ["pass", "shot", "carry", "take_on"]
        }
    )

    # start working with dataset

or Opta event data

from kloppy import OptaSerializer

serializer = OptaSerializer()

with open("f24_data.xml", "rb") as f24_data, \
        open("f7_data.xml", "rb") as f7_data:

    dataset = serializer.deserialize(
        inputs={
            'f24_data': f24_data,
            'f7_data': f7_data
        },
        options={
            "event_types": ["pass", "shot"]
        }
    )

    # start working with dataset

or Metrica Json event data

from kloppy import MetricaEventsJsonSerializer

serializer = MetricaEventsJsonSerializer()

with open("eventdata.json", "rb") as event_data, \
        open("metadata.xml", "rb") as metadata:

    dataset = serializer.deserialize(
        inputs={
            'event_data': event_data,
            'metadata': metadata
        },
        options={
            "event_types": ["pass", "shot"]
        }
    )

    # start working with dataset

or Sportec XML event data

from kloppy import SportecEventSerializer

serializer = SportecEventSerializer()

with open("eventdata.xml", "rb") as event_data, \
        open("match_data.xml", "rb") as match_data:

    dataset = serializer.deserialize(
        inputs={
            'event_data': event_data,
            'match_data': match_data
        },
        options={
            "event_types": ["pass", "shot"]
        }
    )

    # start working with dataset

or WyScout JSON event data

from kloppy import WyscoutSerializer

serializer = WyscoutSerializer()

with open("events.json.xml", "rb") as event_data:
    dataset = serializer.deserialize(
        inputs={
            'event_data': event_data
        },
        options={
            "event_types": ["pass", "shot"]
        }
    )

    # start working with dataset

Transform the pitch dimensions

Data providers use their own pitch dimensions. Some use actual meters while others use 100x100. Use the Transformer to get from one pitch dimensions to another one.

from kloppy.domain import Transformer, PitchDimensions, Dimension

# use deserialized `dataset`
new_dataset = Transformer.transform_dataset(
    dataset,
    to_pitch_dimensions=PitchDimensions(
        x_dim=Dimension(0, 100),
        y_dim=Dimension(0, 100)
    )
)

Transform the orientation

Data providers can use different orientations. Some use a fixed orientation and others use ball owning team.

from kloppy.domain import Transformer, Orientation

new_dataset = Transformer.transform_dataset(
    dataset,
    to_orientation=Orientation.BALL_OWNING_TEAM
)

Transforming pitch dimensions and orientation at the same time

from kloppy.domain import Transformer, PitchDimensions, Dimension, Orientation

# use deserialized `dataset`
new_dataset = Transformer.transform_dataset(
    dataset,
    to_pitch_dimensions=PitchDimensions(
        x_dim=Dimension(0, 100),
        y_dim=Dimension(0, 100)
    ),
    to_orientation=Orientation.BALL_OWNING_TEAM
)

Transforming a dataset to a different provider coordinate system

from kloppy.domain import Transformer, Provider

# use deserialized `dataset`
new_dataset = Transformer.transform_dataset(
    dataset,
    to_coordinate_system = Provider.TRACAB,
)

API Overview

FAQ

I'm a data provider, how can we collaborate?
